Coaxial Double Cylinder Rotational Viscometer Drilling Fluids Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-CDCRV
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Drilling Fluids Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Coaxial Double Cylinder Rotational Viscometer Power Supply: AC220V±5% 50/60Hz
Reproducibility: ± 1% (F.S Newtonian Fluid) Instrument Power Consumption: ≤ 40W
Ambient Humidity: ≤ 80% Application: Drilling Fluids Testing Equipment

Product Description

Coaxial Double Cylinder Rotational Viscometer Drilling Fluids Testing Equipment



Description:

This instrument is a general coaxial cylinder up rotation viscometer. It is suitable for industrial and mining enterprises and research departments to accurately measure the viscosity of various Newtonian fluids and the rheological properties of non Newtonian fluids in the laboratory. It can be used in paint, resin, chemical fiber, mineral oil, lubricating oil, cosmetics, sugar paddle, mud, insulating materials, etc. The instrument can be placed in the laboratory for sampling and testing, It can also be held in the hand and inserted into the liquid for portable measurement. The instrument has the characteristics of small volume, light weight, rapid measurement, convenient reading and accurate indication. The rotating speed, rotor and outer cylinder are available in a variety of specifications, which can meet a wide range of measurement. The rotary drum system is made of stainless steel and has strong capacity.us materials Drilling Fluids Testing Equipment.



Specification:

Application Drilling Fluids Testing Equipment
Power Supply
220V ± 22V 50Hz ± 0.5Hz
Measuring range( η )
2.8 mPa. s~1.78 × 107 mPa. s
Shear stress( τ)
27.67 Pa~21970 Pa
Shear rate (d)
1.23 S-1 ~ 996 S-1
Speed
5.6 r/min ~ 360 r/min
Reproducibility
± 1% (F.S Newtonian fluid)
Material temperature range room temperature
~ 70 ℃
Instrument weight
≤ 12 kg
Instrument power consumption
≤ 40W
Ambient temperature
+5 ℃ ~ 35 ℃
Ambient humidity
≤ 80%

Coaxial Double Cylinder Rotational Viscometer Drilling Fluids Testing Equipment 0

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
