Hebei Better United Import And Export Co., Ltd.

Capillary Absorption Time Meter Drilling Fluids Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: LS-1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Drilling Fluids Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Capillary Absorption Time Meter Drilling Fluids Testing Equipment Power Supply: AC220V±5% 50/60Hz
Working Pressure: 100psi(690±35)kPa Filtration Area: (4580±60)mm2
Overall Dimension: 152*140*76 Application: Drilling Fluids Testing Equipment

Product Description

Capillary Absorption Time Meter Drilling Fluids Testing Equipment

Description:
The capillary absorption time tester measures the time required for the slurry composed of various test solutions and shale powder to penetrate a certain distance through the special filter paper. This value is called CST value. Its size is related to the properties of liquid, colloidal dispersion and other factors, and can be used to determine the colloidal dispersion degree of shale in water. The smaller CST value is, the better the inhibition effect is. The smaller CST value indicates: (1) small shale hydration effect; (2) Small colloidal dispersion; (3) Shale activity. The capillary absorption time tester can be used in many fields, such as sewage treatment (rapid testing of sludge filtration characteristics and status), testing and research of oilfield chemical treatment agents (evaluating the ability of mud to inhibit dispersion, the anti swelling ability of drilling fluid, the ability of drilling fluid to inhibit hydration and dispersion, and optimizing the formula of working fluid entering the well, such as the type, dosage and ratio of treatment agents, and can also be used as a new tool for analyzing and evaluating shale classification) Drilling Fluids Testing Equipment

Specification:

Application Drilling Fluids Testing Equipment
Power Supply
AC220V±5% 50/60Hz
Filtration area
(4580±60)mm2
working pressure
100psi(690±35)kPa
Overall dimension
152×140×76

Capillary Absorption Time Meter Drilling Fluids Testing Equipment 0

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
