Digital Four Wire Soil Resistivity Tester Automatic Soil Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-SRTER4300
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Soil Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Digital Four Wire Soil Resistivity Tester Automatic Soil Testing Equipment Measuring Range And Accuracy: (23℃5℃,relative Humidity 45~75%RH)
6 Ranges Within The Range: 0.001 Ω - 200K Ω Dot-matrix: 192x64
Monochrome: LCD Application: Soil Testing Equipment

Product Description

Digital Four Wire Soil Resistivity Tester Automatic Soil Testing Equipment



Description:

It is specially designed for on-site measurement of grounding resistance and adopts digital and micro processing technology. It has a unique line resistance calibration function, anti-interference ability and environmental adaptability to ensure high accuracy, high stability and reliability of long-term measurement. It is widely used in the measurement of grounding resistance of electric power, telecommunications, meteorology, oil fields, buildings, lightning protection and industrial electrical equipment.Soil Testing Equipment



Features:

  • 2/ 3/ 4-Wire Digital Earth Resistance
  • Designed to meet following safety standards.
  • IEC 61010-1 (CAT. III 300V, CAT. IV 150V, Pollution degree 2)
  • IEC 61010-031(Requirements for hand-held Probes)
  • IEC 61557-1, 5 (Earth Resistance Tester) Soil Testing Equipment
  • Stable measurement results can be obtained under a noisy environment by introducing the FFT (Fast Fourier Transform) technology.
  • Dot-matrix 192x64, Monochrome LCD.
  • Backlight function to view the test results in dimly areas.
  • Can switch frequencies of measuring signal4-kind of frequencies : 94 / 105 / 111 / 128Hz, are selectable by hand or automatically.
  • Rk Function is available to cancel the residual resistance on the Test Leads.
  • Battery Check Function
  • Can measure Series Interference Voltage/ Frequency Voltage values and frequencies are displayed when Series Interference voltage (AC) exist.
  • Auxiliary earth resistances are measured and displayed
  • Warnings are displayed on the LCD when auxiliary earth resistances are too high and may result in inaccurate measurements.
  • Auto-Power-Off Function.
  • The instrument is automatically powered off when 5 min passes without any Key operation.
  • Memory Function. Can save 800 measured results.
  • Direct measurement of soil grounding rate by quadrupole method
  • Grounding resistance test of 6 ranges within the range of 0.001 Ω - 200K Ω
  • After setting the spacing of auxiliary grounding rods, the grounding resistance test results are automatically calculated
  • Warning function in case of super interference or high auxiliary grounding resistance
  • Automatic mode, the instrument automatically selects the most appropriate frequency Soil Testing Equipment

Specification:

Measuring range and accuracy (23℃5℃,relative humidity 45~75%RH)

Digital Four Wire Soil Resistivity Tester Automatic Soil Testing Equipment 0

Digital Four Wire Soil Resistivity Tester Automatic Soil Testing Equipment 1
