Porous Disc Soil Testing Equipment

Product Description

Porous Disc

Standards:

BS1377, ASTM D2850 D4767

Description:

• Porous Disc has high permeability and low gas permeability. The Porous Disc is carefully selected to ensure that it will not deform under high pressure when used in triaxial apparatus, consolidation apparatus, direct shear apparatus, permeameter and other tests Soil Testing Equipment
• Porous Disc can be used in triaxial tests, and it has many specifications. Diameters of 39.1 and 44 can be used in triaxial apparatus experiments. 61.8 in diameter can be used for consolidation instrument and direct shear instrument, and some specifications can be used for permeameter.Soil Testing Equipment

Features:

• The Porous Disc is made of emery, which has high permeability and can make water × It passes at a speed of 10-8m/s and has very low air permeability. Soil Testing Equipment
• The Porous Disc is carefully selected to ensure that it will not deform under high pressure in the test.
• Soil Testing Equipment

Specification:

￠ 39.1*5mm permeable stone is used for triaxial apparatus;

￠ 44*5mm permeable stone, used for triaxial apparatus;

￠ 61.8*10mm permeable stone is used for saturator, triaxial apparatus and permeameter;

￠ 79.8*10mm permeable stone is used for stacked saturator, consolidator and direct shear apparatus;

￠ 83*10mm permeable stone is used for stacked saturator and consolidator;

￠ 110*10mm permeable stone is used for triaxial apparatus;

Other sizes can also be customized

￠12*5mm ￠28*5mm ￠28*10mm ￠38*5mm ￠38*10mm ￠44*5mm ￠50*10 mm ￠63.2*6.4mm

￠61.8*12.7mm ￠70*10mm ￠90*10mm ￠95*10mm ￠100*10mm

￠105*10mm ￠110*10mm ￠ 150*10mm ￠200*12mm ￠280*20mm .

Square:151*151*10mm ,100×100×8 ,100×100×10,60*60*8mm
