Soil Lathe Soil Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-SL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Soil Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Soil Lathe Standard: ASTM/BS
Sample Sizes: 39.1mm, 61.8mm, 101mm, 35mm, 38mm, 50mm, 70mm And 100mm Dimensions (W X D X H) : 230 X 320 X 460mm
Weight: 9KG Warranty: 1 Year

Product Description

Soil Lathe



Standards:

BS1377, ASTM D2850 D4767



Description:

Soil Lathe ( Sample trimmers ) is designed to be easy to operate and accurately trim soil samples for triaxial , shear , unconfined compression , and other tests requiring standard cylindrical specimens 39.1mm, 61.8mm, 101mm, 35mm, 38mm, 50mm, 70mm and 100mm diameter samples, the frame is of a study 3 column design and has an adjustable trimming guide to ensure precision , The upper platen is adjustable to accommodate different sample sizes ( up to 225mm high ), and both upper and lower platens have grips to keep the sample securely in place whilst trimming.Soil Testing Equipment





Features:

  • Made of lightweight alloy
  • Hard anodised coating to minimal corrosion
  • Supplied with platens for 35, 38, 50, 70 & 100 mm Sample
  • Soil Testing Equipment



Specification:

Sample Sizes 39.1mm, 61.8mm, 101mm, 35mm, 38mm, 50mm, 70mm and 100mm
Dimensions (W x D x H) 230 x 320 x 460mm
Weight 9kg



Soil Lathe Soil Testing Equipment 0

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Soil Testing Equipment

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Soil Testing Equipment

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
