60kN Triaxial Test Systems Soil Testing Equipment

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-TTS60
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Triaxial Test Systems 60kN Standard: ASTM/AASHTO/BS
Power Supply: 220v Specimen Size: Φ 39.1 80mm Φ 61.8mm 125mm 101mm 200mm
Load: 60kn Table Stroke: 0mm-90mm
Strain Rate: 0.0024-4.5mm/min Electronic Transmission Shear Rate: 0.001-4.800mm/min

Product Description

60kN Triaxial Test Systems Soil Testing Equipment



Standards:

ASTM D2850, D4767, D7181; AASHTO T-297; BS 1377-7, BS 1377-8



Description:

  • It is used for teaching tests in general geotechnical laboratories and colleges and universities.
  • The instrument is of strain control type, which is used to measure the maximum surrounding pressure of 1.0MPa, with a diameter of ф The triaxial shear test of strength and deformation characteristics of 39.1mm soil samples under axial static load can be carried out by unconsolidated undrained shear (UU), consolidated undrained shear (CU) and consolidated drained shear (CD).Soil Testing Equipment
  • The instrument has high confining pressure, compact structure and simple operation. It does not need to be equipped with air compressor and nitrogen cylinder, and can meet the requirements of geotechnical tests of large civil engineering projects such as high-rise buildings and dams.Soil Testing Equipment

Features:

  • Convenient operation and high accuracy
  • Stable speed and reliable performance
  • Beautiful appearance, easy to use, durable
  • Soil Testing Equipment



Specification:

Model
F-10
F-30
Max load
10KN
30KN
Sample dimension
diameter39.1×80 mm
diameter39.1×80 mm, diameter61.8×125 mm
Strain rate
0.016-1.6mm/min.
six-speed mechanical transmission
0.0024-4.5mm/min.
16-speed mechanical transmission
Table stroke
Max. 50mm
Max. 90mm
Confining pressure
0-2Mpa
0-2Mpa
Back pressure
0-1.0Mpa
0-1.0Mpa
Volume change
0-50ml/0.1ml
0-50ml/0.1ml
Hole pressure
0-2Mpa
0-2Mpa
Axial displacement
0-30mm
0-30mm
Power
220V±10%
220V±10%
Machine dimension
350x300x1100mm (LxWxH)
500x430x1200mm (LxWxH)
Controller Dimension
500x500x925mm (LxWxH)
500x500x925mm (LxWxH)
Weight
170KG
180KG



60kN Triaxial Test Systems Soil Testing Equipment 0

About Us:

260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.

Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.

Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.



Our Advantage:

Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.

Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.

Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.

Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.

Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.

Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
