ASTM Speed 1.27mm Soil Test Equipment CBR Test Machine With Load Ring

Product Description

ASTM Speed 1.27 mm CBR Test Machine Soil Test Equipment With Load Ring

Standards:

BS 1377, 1924; EN 13286-47; ASTM D1883; AASHTO T193; NF P94-078

Description:

1.CBR Test Machine is suitable for test of soils and mix materials(the grain size of the soil is less than 40mm) compacted with 2.CBR mold so as to confirm the bearing loading ability of pavement, roadbed subcrust as well as material layer of the roadbed to be designed Soil Test Equipment

3.Load the penetration piston into the soil sample at a constant rate to measure the applied load and piston penetration at predetermined intervals Soil Test Equipment

4.Comprises of a robust and compact two column frame with adjustable upper cross beam. The frame has 50 kN capacity. The test speed is 1.27 mm/min. for ASTM/EN/AASHTO/BS/NF tests.

Features:

• Single speed machine
• Rapid platen adjustment
• Complete with stabilising bar
• Compact, bench-mounting design
• Options for mechanical or electronic measurement
• Upper beam an be adjusted in height.
• Foreseen of fast approach device of the base plate and electric end of stroke switches of the load plate to save the machine from wrong

Specification:

CBR Test Machine comprises:

• CBR motorized frame
• CBR penetration piston
• Load ring 50 kN capacity
• Dial gauge 10 x 0.01 mm
• Dial gauge holder

​
