GB5211.17-88 Paint Film Reflectance Meter

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-PPFRT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Paint Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Portable Paint Film Reflectance Tester Standard: ISO3906-1980(E)、GB/T13452.3-92、GB9270-88、GB5211.17-88
Warranty: 1 Year Measuring Range: 0 ~ 100%
Measuring Accuracy: 1.5% Working Voltage: 0.8v ~ 1.5v
Highlight:

GB5211.17-88 Reflectance Meter

,

Paint Film Reflectance Meter

Product Description

Portable Paint Film Reflectance Tester Paint Testing Equipment



Standard:

ISO3906-1980(E),GB/T13452.3-92,GB9270-88,GB5211.17-88



Features:

1. The ultra-small design can be put in the pocket, which is more convenient for carrying and field measurement.

2. Zero calibration is not needed and the operation is simple.

3. Super power saving design, using a no. 5 battery (either rechargeable battery or alkaline battery), can be operated.A new battery can be used continuously for more than 50 hours and can measure about 10,000 data.

4, special moisture-proof process can let you rest assured in a variety of harsh environment.

5, long life light source, no need to replace.

6. National calibration whiteboard delivers standard values, which is accurate and reliable.



Description:

Mn-r is a portable reflectance meter newly developed by our company, which is convenient for customers to carry. It is convenient for field measurement and development.It is used to determine the hiding power of paints, varnishes - light paints, pastes, pigments and various colorants on substrates.Paint Testing Equipment



Specification:

1. Measuring range 0 ~ 100%
2. Testing conditions 0/45 (0 ° receiving, 45 ° transmitting)
3. Measuring accuracy 1.5%
4. Working power supply a no.5 (AA) alkaline battery or rechargeable battery
5.Working voltage 0.8v ~ 1.5v
6.Measuring aperture 12×17mm (ellipse)
7.Operating conditions ambient temperature: 0℃ ~ 40℃
8.Relative humidity not more than 85%
9.Host size (length)114mm×(width)32mm×(height)64mm
10.Weight of main engine 300g
