50.8 Speed Marshall Stability Tester Machine 50kN

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU-MST
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Asphalt Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: 50.8 Speed Marshall Stability Tester Asphalt Testing Equipment Standard: EN 12697-34 ASTM D1559 ASTM D5581 AASHTO T245 NF P98-252-2
Maximum Rated Load: 50kN Motor Specification: 220V, 0.37kw, 1440rpm, Three-phase Operation
Working Voltage: AC 220V50Hz Application: Asphalt Testing Equipment
High Light:

Marshall Stability Tester 50kN

,

50.8 Speed Marshall Stability Tester

Product Description

50.8 Speed Marshall Stability Tester Asphalt Testing Equipment



Standard:

EN 12697-34 ASTM D1559 ASTM D5581 AASHTO T245 NF P98-252-2



Features:

1. It is equipped with overload protection and falling over position protection.

2. Simple operation, accurate test data, stable and reliable performance.

3. Automatic test of the instrument, with manual lifting and lowering function, can make the tray in the proper position.

4. There are two kinds of flow value detection: single channel and double channel.

5. You can select large indenter for large Marshall test, or double indenter for large and small tests.

6.Asphalt Testing Equipment



Description:

It is applicable to determine the thermal stability and the ability to resist plastic deformation stability and flow value of asphalt mixture, and provide accurate basis for the composition and proportion design of asphalt mixture. It can accurately judge the damage point of asphalt mixture to carry out the mix proportion design of asphalt mixture or the construction quality inspection of asphalt pavement.Asphalt Testing Equipment



Specification:

Vertical rising speed of test instrument tray 50 + 5mm / min
Maximum moving distance of tester tray 70mm
working range of force value 0-50.00kn
Displacement working range 0-10.00mm
Measuring accuracy of force measuring device ± 0.1kn
Measurement accuracy of displacement measuring device 0.01mm
Working voltage AC 220V50Hz
Motor specification 220V, 0.37kw, 1440rpm, three-phase operation
Maximum rated load 50kN
Service conditions ambient temperature 0 ℃ - 60 ℃, relative temperature < 85%
