Product Details:
|
|
Place of Origin: | Made in China |
---|---|
Brand Name: | Btutest |
Certification: | SGS, INTERTEK |
Model Number: | XQM-0.2S |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | Laboratory Testing Equipment Standard export wooden box |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 3000 sets per month |
Detail Information |
|||
Name: | Miniature Planetary Ball Mill | Warranty: | 1 Year |
---|---|---|---|
Total Time Of Operation Setting: | 1-9999 | Power Supply: | 220V/50HZ |
Application: | Laboratory Testing Equipment | ||
Highlight: | 50HZ Miniature Planetary Ball Mill,220V Miniature Planetary Ball Mill |
Product Description
Miniature Planetary Ball Mill Laboratory Testing Equipment
Features:
The equipment shell adopts semi-circular design elements, high-precision die stamping forming, generous and delicate, high-end and stable; The machining parts are processed by numerical control, the planetary disk is integrally cast and formed, and the transmission gears are precision gears of special materials to ensure that the equipment is stable and quiet during high-speed operation; The pressing device of the grinding tank is easy to operate, safe and reliable.
Description:
Micro planetary ball mill is an optional device for mixing, fine grinding, small sample preparation, new product development and small batch production of high-tech materials. Our planetary ball mill is small in size, full in function, high in efficiency and low in noise. It is an ideal equipment for scientific research institutions, colleges and universities, and enterprise laboratories to obtain research samples (four samples can be obtained at the same time in each experiment). Equipped with a vacuum ball mill, it can grind test samples under vacuum.Laboratory Testing Equipment
Product use:
The micro planetary ball mill is divided into glove box type (model xqm-0.2s) and conventional type (model xqm-0.2). The special type of glove box can be placed in the glove box for vacuuming or inert gas protection, which expands the scope of use for product grinding and material research for customers, so that some materials that cannot be milled in the normal environment can be milled.
Specification:
Model | power supply | rated power (kw) | revolution | rotation | Total time of operation setting | Positive and negative alternate operation time | Noise SDB | |
PM-0.4A | 220V/50HZ | 0.25 | 45-335 | 90-870 | 1-9999 | 1-999 | 58±5 | |
PM-2A | 220V/50HZ | 0.75 | 35-335 | 70-670 | 1-9999 | 1-999 | 60±5 | |
PM-4A | 220V/50HZ | 0.75 | 35-335 | 70-670 | 1-9999 | 1-999 | 60±5 | |
PM-8A | 220V/50HZ | 1.5 | 35-290 | 70-580 | 1-9999 | 1-999 | 60±5 | |
PM-10A | 220V/50HZ | 1.5 | 35-290 | 70-580 | 1-9999 | 1-999 | 60±5 | |
PM-12A | 220V/50HZ | 1.5 | 35-290 | 70-580 | 1-9999 | 1-999 | 60±5 | |
PM-16A | 380V/50HZ | 3 | 30-255 | 60-510 | 1-9999 | 1-999 | 65±5 |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Universal Testing Equipment.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
