Cross Hole Ultrasonic Tester Two Channels

Product Details:
Place of Origin: Made in China
Brand Name: Btutest
Certification: SGS, INTERTEK
Model Number: BTU920
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Concrete Testing Equipment Standard export wooden box
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000 sets per month
  • Detail Information
  • Product Description

Detail Information

Name: Cross Hole Ultrasonic System TWO Channels Standard: ASTM D6760-02
Warranty: 1 Year Master Control Unit: Buit-in A8 Industrial Control Motherboard
Display: 10.1 Inch, High Brightness, TFT Color LCD Capacitive Screen Operational Mode: Touch Screen
High Light:

Cross Hole Ultrasonic Tester Two Channels

,

ASTM D6760-02 Cross Hole Ultrasonic Tester

Product Description

Cross Hole Ultrasonic System Two Channels Concrete Testing Equipment



Standard:

ASTM D6760-02



Features:

※ newly upgraded wireless cloud transmission function (optional);

※ it integrates six functions of pile, strength, defect, width, depth and pavement bending resistance;

※ with stable performance and powerful functions, it is the choice of users with diversified needs in engineering testing, teaching and scientific research;

※ semi reflective and semi transparent, high brightness, TFT color LCD display;

※ full touch screen operation, simple and convenient, stable and reliable;

※ large memory capacity and working time of more than 10 hours;

※ it can be connected to the digital rebound meter probe for ultrasonic rebound comprehensive strength measurement;

※ the U disk is used to transfer data and support software upgrading through the U disk;

※ the special analysis software has powerful functions, and data analysis and processing, report generation, and printing of reports can be easily completed.

※ the Chinese and English interfaces can be switched freely, making it more convenient for foreign customers to use.



Description:

Rapid and continuous detection of foundation piles by ultrasonic transmission method; Rapid detection of continuous wall integrity; Structural concrete compressive strength test; Detection of crack depth of structural concrete; Detection of crack width of structural concrete; Bending resistance test of concrete pavement; Mechanical property testing of non-metallic materials such as rock mass and concrete.Concrete Testing Equipment



Specification:

Product Model BTU920
Master control unit Buit-in A8 industrial control motherboard
Display 10.1 inch, high brightness, TFT color LCD capacitive screen
Operational mode Touch screen
Storage mode Built-in Electronic Hard Disk(>8GB)+Large Capacity U Disk
Data transmission mode Wireless Cloud Transport(Options)
Acquisition mode Manual point-by point collection of single and double channels
Number of dispossable profiles
Channel number 1 emission+2 reception
Trigger mode Signal triggering
Sampling period(mus) 0.05~409.6 Multistage Options
Acoustic time accuracy(us) 0.05
Acoustic time range(mus) +1677700
Width measurement function Measuring range: 0~10mmMeasurement accuracy: 0.01mm
Dynamic range(dB) 0.5
Emission voltage(V) Sixty-five, 250, 500 and 1000 gears adjustable
Communication interface UBS, Bluetooth, Wifi
Working hours(h) More than 8
Power supply mode Built-in lithium batteryExternal 220V~ 16V AC/CD
Working environment Temperature(℃) -10℃~ + 40℃Humidity(RH) <90%
Host size(mm) 300*200*55

Cross Hole Ultrasonic Tester Two Channels 0Cross Hole Ultrasonic Tester Two Channels 1Cross Hole Ultrasonic Tester Two Channels 2
